RAM Mount RAM Tough-Mag 48MM 4-Point Magnetic Mounting Base

RAM Tough-Mag 48MM 4-Point Magnetic Mounting Base

The RAM Tough-Mag Magnetic Window Mount (RAM-MAG48-4U) consists of a steel plate with four magnetic ends and four 48mm external magnets for mounting on a window, or any other flat glass surface. The plate contains pre-drilled 4-hole AMPS and VESA patterns for attaching a recommended C, or D-size drill-down ball base. The base is designed with rubber-coated magnets to prevent scratching the mounting surface and reduce the impact of the jarring magnetic pull. Each external magnet includes a handle to easily install the base to a window. Compatible with any sturdy, flat surface up to 6mm in thickness.

Features:

• Four-point steel plate with 2 sets of 4 rubber coated external magnets for attaching to windows up to 6mm in thickness


• 4-hole AMPS and VESA patterns for attaching C or D size RAM drill-down ball bases


• External magnets include handles for ease of installation


• Backed by a lifetime warranty

Specifications:

• Hardware Included: Assembly Hardware(8) #4-40 x 1/4 Machine Screws(4) #10-24 x 3/4 Machine Screws(4) #10-24 Nylock Nuts(4) Rubber Caps


• Product Dimensions: Overall Length: 8.99Overall Width: 8.99Overall Thickness (inside surface): 1.64


• Hole Pattern: 4-Hole AMPS: 1.181 x 1.496, 75 x 75mm VESA


• Packaging Type: Poly Bag


• Weight: 4.65 lbs
